CDT3 CDT3MT1 CYM1MFX CYL1MP5 Series CYL1MP5/63/36/280D10/B1XKUXS40282 R407035741 Hydraulic Cylinder

OEM CDT3, CDT3MT1, CYM1MFX, CYL1MP5 Series Hydraulic Cylinder – Model: CYL1MP5/63/36/280D10/B1XKUXS40282 (Part Number: R407035741)
Explanation:
1. Term Definition
* OEM: Stands for “Original Equipment Manufacturer”. Here, it indicates that this hydraulic cylinder can be used as an
original equipment component (i.e., a part supplied directly for the assembly of original machinery).
* Series: A classification term used to group hydraulic cylinders of the same type and design standard, facilitating product
management and selection.
* Hydraulic Cylinder: A hydraulic actuator that converts hydraulic energy into linear reciprocating mechanical energy. It is
widely used in industrial machinery, construction equipment, and other fields requiring hydraulic transmission.

2. Model & Part Number Description
* “CDT3, CDT3MT1, CYM1MFX, CYL1MP5” are all product series codes. Different codes correspond to differences in the hydraulic
cylinder’s mounting type, structural design (e.g., tie-rod type, welded type), and other core features. For specific
meanings, please refer to the manufacturer’s technical manual.
* “CYL1MP5/63/36/280D10/B1XKUXS40282” is the specific model. Typically, the numbers in the model represent key technical
parameters (as inferred in the previous response: “63” refers to a piston diameter of 63mm, “36” to a piston rod diameter
of 36mm, and “280” to a stroke of 280mm). The letters indicate details such as seal type, oil port design, and piston rod
configuration—coding rules may vary by manufacturer.
